Reference Audio EOS 10000.5

Reference Audio EOS 10000.5 – Compact 5-Channel Class-D Power Amplifier

The Reference Audio EOS 10000.5 is a powerful yet compact 5-channel Class-D amplifier built for clear and efficient sound. It is designed for flexibility, and it can power both full-range speakers and a subwoofer in one unit. As a result, it is a great choice for clean and competition-level car audio systems.

In addition, the EOS 10000.5 sets a high standard for compact multi-channel amplifiers. It includes four full-range channels and one dedicated subwoofer channel. Therefore, it can run a complete audio system with ease.

Moreover, the amplifier delivers up to 115W per channel for speakers. At the same time, it produces 510W at 1Ω for the subwoofer. Because of this, you get clear highs, smooth mids, and deep, controlled bass.

Furthermore, the EOS 10000.5 uses advanced Class-D technology. As a result, it reaches up to 90% efficiency, which helps reduce strain on your electrical system. In turn, it also lowers heat output during use.

In addition, the amplifier includes useful tuning features. For example, it has an adjustable crossover network and a bass boost control. Because of these options, you can fine-tune the sound to match your setup.

Finally, it also includes built-in protection systems. These include thermal, overload, and short-circuit protection. Therefore, the amplifier remains reliable even under heavy use.

Features

• Power Output: 75W x 4 + 190W x 1 @ 4Ω / 115W x 4 + 300W x 1 @ 2Ω / 510W x 1 @ 1Ω (sub only)
• Frequency Response: 10Hz – 40kHz (Full Range) / 10Hz – 200Hz (Sub)
• High Efficiency: 90% @ 4Ω load
• Compact Design: Slim 180 x 55 x 201 mm footprint
• Class-D Technology: Efficient power delivery with low heat output
• Selectable Crossover: Includes adjustable low-pass and bass boost controls
• Protection Circuitry: Thermal, overload, short circuit, and clipping LED protection
• Build Quality: Premium components with durable construction
• Minimum Impedance: Stable down to 1Ω on sub channel
• Input Range: 320mV – 7V low-level inputs

Specifications
